Server Specifications

Integrated with iTel Switch Plus, iTel Billing is a real-time billing and monitoring system. Below given is the server specification based on number of concurrent calls.

Concurrent Calls Server Specification Number of Servers Use of Servers
120 Pentium-4, 3GHz
Memory- 2GB
Disk Size- 80 GB
1 Authentication and accounting will be done in the same server
240 Pentium-4, 3GHz
Memory- 2GB
Disk Size- 80 GB
1 Authentication and accounting will be done in the same server
360 Xeon, 2.8 GHz
Memory- 4GB
Disk Size- 120 GB
1 Authentication and accounting will be done in the same server
480 Dual Xeon, 2.8 GHz
Memory- 4GB
Disk Size- 120 GB
2 One server is dedicated for authentication and another server is dedicated for accounting
1000 Dual Xeon, 3.0 GHz
Memory- 8GB
Disk Size- 120 GB
2 Two servers are dedicated for authentication and another server is dedicated for accounting
3000 Dual Xeon, 3.0 GHz
Memory- 16GB
Disk Size- 120 GB
2 One servers are dedicated for authentication and another server is dedicated for accounting
5000 Dual Xeon, 3.0 GHz
Memory- 16GB
Disk Size- 120 GB
2 Two server is dedicated for authentication and another server is dedicated for accounting

A schematic diagram of VoIP infrastructure incorporating iTel Billing

Operating System Windows, Linux/Unix.
Browsers

Internet Explorer 5 or higher

Netscape 6.2 or higher

Mozilla Firefox 1.0 or any web-browser supporting DOM and with JavaScript enabled

Display Settings Minimum Screen Resolution : 1024 x 768 Color Palette- 16 bit color (minimum)
